Foundation analysis and repair design
Permanent structural crack bonding
Bowing wall stabilization systems
Written coverage on all repair work
Not every crack you find in your foundation wall signals a structural problem, but every crack deserves a professional evaluation because the consequences of misclassifying a structural crack as cosmetic are serious. Our assessment process includes measuring crack width at multiple points, documenting the orientation precisely, checking for horizontal displacement at the crack face, and reviewing the soil and drainage conditions outside the wall. The result is a categorization of the crack as cosmetic, water-entry, or structural -- each with a different repair recommendation.
The repair method matched to horizontal cracks depends on the degree of deflection and the construction type of the wall. For poured concrete walls with deflection below critical thresholds, a carbon fiber strap system bonded to the wall face with structural epoxy provides a tensile reinforcement layer that counteracts the lateral earth pressure. For block walls, carbon fiber straps bonded to a plate assembly anchored into the slab and rim joist provide the same function. In both cases the straps are virtually invisible after installation and do not require interior space to accommodate them.
Polyurethane injection is specified for cracks where flexibility is a design requirement rather than structural re-bonding. Polyurethane foam expands as it cures to fill irregular voids completely, including cracks that are not perfectly planar. The cured foam remains flexible, allowing the wall to undergo minor seasonal movement without reopening the seal -- a characteristic that makes polyurethane the right choice for active cracks where temperature-driven concrete expansion and contraction may continue. Polyurethane injection is also used in wet crack conditions because the foam reacts with water during its cure, making moisture in the crack an asset rather than an obstacle to the seal.
Soil settlement beneath footings is an independent cause of foundation cracks that requires evaluation separately from the wall repair itself. When soil compresses or washes out from beneath a footing, that section of the foundation wall loses its support and the wall may develop diagonal cracks as the unsupported section deflects downward. In these cases, crack injection addresses the symptom while leaving the root cause unresolved. Our assessment includes a review of grading, drainage, and visible footing conditions to identify signs that settlement is active. Where settlement is a factor, we coordinate the repair approach to address both the crack and the soil condition that created it, preventing recurrence after the crack is sealed.
From hairline seepage cracks to structural horizontal cracking, we have the right fix.
We use two-component structural epoxy formulated for below-grade conditions and sized for the crack width encountered, ensuring complete penetration and full void fill before final curing.
Polyurethane injection is the correct choice for actively weeping cracks where water presence would compromise epoxy adhesion -- the foam reacts with moisture to accelerate its cure and seal the void from the inside out.
We calculate strap spacing and quantity based on the measured deflection, wall height, and soil pressure conditions at each job so the reinforcement is engineered for your specific wall rather than generically applied.
Wall anchors can be tightened over time as the soil condition allows, potentially restoring some of the original wall plumb position without excavation or more invasive structural work.
We repair stair-step cracks by tuck-pointing the affected mortar joints with a compatible mortar mix matched to the existing wall, reinforcing corner crack locations, and applying a crystalline waterproofer to the repaired area to prevent water intrusion at the newly bonded joints.
We seal the floor-wall joint with a combination of hydraulic cement at active leak points and a flexible polyurethane sealant bead over the sealed joint to accommodate minor movement without allowing the seal to crack again.
Crack mapping, moisture readings, and wall plumb measurements are documented in a written report that accompanies your quote.
We match the repair method to the specific crack condition -- epoxy for structural re-bonding, polyurethane for active water and flexible seal requirements, carbon fiber for bowing walls.
Carbon fiber installations include verification of bond strength and strap spacing against the engineered design before the job is signed off.
A written warranty is issued on project completion, covering the repair against reoccurrence under normal conditions for the warranty period stated in your contract.
We had a 14-foot horizontal crack in our block wall that two other companies dismissed as not serious. JCB Waterproofing and Construction came in, took actual measurements, and explained exactly why it needed carbon fiber straps immediately. The repair looks clean and the wall has not moved since.
I was told by two contractors that my diagonal cracks were just cosmetic. JCB Waterproofing and Construction measured the crack width at three points and showed me they were widening. The epoxy injection repair was completed cleanly and the cracks have been stable for over a year.
Our basement had a floor-wall joint that was allowing water in during every heavy rain. JCB Waterproofing and Construction sealed it properly with hydraulic cement and a polyurethane bead. No water in two rainy seasons since. Clean, professional work.
Don't let a small crack become a structural emergency. Contact JCB Waterproofing and Construction for a written evaluation and quote in Raymond, IL.
Call +1-866-476-1348 Now
